ThunderLink® - Thunderbolt™ Storage Adapters
ThunderLink® Thunderbolt™ 2 and 3 Devices
ATTO's ThunderLink products enable storage and network connectivity for SAS, SATA, Fibre Channel or Ethernet devices for Thunderbolt enabled workbooks and workstations. ATTO ThunderLink products are focused on prosumer and professional markets where performance and latency management are key. With Thunderbolt connectivity, creative, engineering, and scientific professionals now have access to storage and networks at speeds not previously available. ATTO's exclusive Advanced Data Streaming (ADS™) Technology provides controlled acceleration of data to deliver the highest consistent performance and reliable data transfers for video editing, digital audio, video on demand, graphics, or database applications.
- Widest range of Thunderbolt™ connectivity to Fibre Channel, SAS/SATA, 40/10GbE storage and networks
- Proven interoperable with leading storage hardware and software vendors
- Simplified user interface for configuration, monitoring and management via ConfigTool™ allows users to easily take control of their storage
- All products fully configured including any needed SFPs and QSFPs
ThunderLink® NQ 3402 (QSFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (2) 40GbE Ethernet
Connector Type: Thunderbolt 3/ QSFP+
ThunderLink® NQ 3401 (QSFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (1) 40GbE Ethernet
Connector Type: Thunderbolt 3/ QSFP+
ThunderLink® NS 3101 (SFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (1) 10GbE Ethernet
Connector Type: Thunderbolt 3/ LC SFP+
ThunderLink® NS 3102 (SFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (2) 10GbE Ethernet
Connector Type: Thunderbolt 3/ LC SFP+
ThunderLink® FC 3322 (SFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (2) 32Gb/s FC
Connector Type: Thunderbolt 3/ LC SFP+
ThunderLink® FC 3162 (SFP+)
Transfer Rate: 40GB/s
Input Connectors: (2) 40Gb/s Thunderbolt
Output Connectors: (2) 16Gb/s FC
Connector Type: Thunderbolt 3/ LC SFP+
ThunderLink®SH 2068
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (8) 6Gb/s SAS/SATA
Connector Type: Thunderbolt2/SFF-8088
ThunderLink® FC 2162
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (2) 16Gb/s FC
Connector Type: Thunderbolt 2/ LC SFP+
ThunderLink® FC 2082
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (2) 8Gb/s FC
Connector Type: Thunderbolt 2/ LC SFP+
ThunderLink® NS 2101 (SFP+)
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (1) 10GbE
Connector Type: Thunderbolt 2/ SFP+ LC
ThunderLink® NS 2102 (SFP+)
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (2) 10GbE
Connector Type: Thunderbolt 2/ SFP+ LC
ThunderLink® NT 2102 (10GBASE-T)
Transfer Rate: 20GB/s
Input Connectors: (2) 20Gb/s Thunderbolt
Output Connectors: (2) 10GbE
Connector Type: Thunderbolt 2/RJ45
